Cudy AX3000 Gigabit Wi-Fi 6 Mesh Router

Description

FM002-WR3000-

The Cudy WR3000 AX3000 Gigabit Dual Band Wi-Fi 6 Mesh Router features a new Wi-Fi 6 chip with a 4-nm made process, delivering amazing powers and an impressive efficiency bump, enabling the AX3000 to maintain responsiveness and handle intensive transmission tasks such as online gaming streams and 4K live feeds. Equipped with Wi-Fi 6, the AX3000 boasts the highest 160Mhz bandwidth and 1024-QAM to reach up to 3Gbps speeds, which is more than 2.5x faster than the last-gen AC 2×2 Wi-Fi router. This high throughput allows massive amounts of data including your 4K video streaming and hopping to end devices without any throttling. The upgraded Wi-Fi 6 standard features downlink and uplink MU-MIMO and OFDMA, providing up to 8X (2.4 GHz) to 16X (5 GHz) greater network capacity to be more responsive under heavy use.

FEATURES:

• Super-Fast AX3000 Wi-Fi 6
• 1.3 GHz Dual-Core Cortex-A53 CPU
• 4× 10/100/1000Mbps Ethernet Ports
• 160 MHz Channel Width
• DL/UL OFDMA and DL/UL MU-MIMO
• Wireguard/OpenVPN/L2TP/PPTP VPN Server and Client
• IPv4/IPv6
• TR069/TR098/TR181/TR111

SPECIFICATIONS:

• Processor: 1.3 GHz Dual-Core ARM Cortex-A53 CPU
• Antennas: 4 × Fixed Omnidirectional Antennas
• Ethernet Ports:
• 1 × 10/100/1000Mbps WAN Port
• 3 × 10/100/1000Mbps LAN Ports
• Buttons: WPS Button, Reset Button
• External Power Supply: 12 V / 1 A
• Product Dimensions without Antennas: 18 x 10.7 x 3.5 cm
• Product Dimensions with Antennas: 20 x 11.7 x 3.5 cm
• Wireless Standards: IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/n/b/g 2.4GHz
• Wireless Frequency: 5GHz, 2.4GHz
• Wireless Bandwidth: 20/40/80/160 MHz
• Signal Rate:
• 2402Mbps (5 GHz), 574Mbps (2.4 GHz)
• Compatible with 802.11a/b/g/n/ac Wi-Fi standards
• Transmit Power:
• CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
• FCC: <30d Bm (2.4 GHz & 5 GHz)
• Wireless Modes: Enable/Disable Wireless Radio, WMM
• Wireless security: WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3
• Other Features: MU-MIMO, Beamforming
• VPN Server and Clinet: Wireguard/OpenVPN/L2TP/PPTP
• DNS over TLS: Cloudflare/Google/Quad9
• WAN Type: Dynamic IP/Static IP/PPPoE
• DHCP: Server, DHCP Client List, Address Reservation
• Dynamic DNS: Compatible with 15 more DDNS providers
• Guest Network:
• 2.4 GHz guest network × 1
• 5 GHz guest network × 1
• NAT: Port Forwarding, Port Triggering, UPnP, DMZ
• System Requirements:
• Microsoft Windows, macOS, NetWare, UNIX or Linux
• Firefox 12.0, Chrome 20.0, Safari 4.0, or other Javascript-enabled browsers
• A Cable or DSL Modem, or other devices providing wired internet
• Subscription with an internet service provider for internet access
• Product Dimensions: 20 x 11.7 x 3.5 cm (Antennas not included)

WHAT’S IN THE BOX:

• Cudy WR3000 AX3000 Gigabit Dual Band Wi-Fi 6 Mesh Router -Black x1
• Power Adapter x1
• RJ45 Ethernet Cable x1
• Quick Installation Guide x1
